Gates Hydraulic Hose – 1” 2SC 2 Wire Compact (Roll) | Sparex Part Number: S.118128 1.14 kg

Brand: Gates
Burst pressure (bar): 688
Burst pressure (psi): 10000
Construction: 2 Wire
Hose inner Ø (ins): 1
Hose outer Ø (mm): 35.1
Maximum Working Pressure (bar): 172
Maximum Working Pressure (psi): 2500
Minimum Bend Radius (mm): 115
Nominal I.D.: DN25
Pack Type: Roll
Reference: 16M2T
Roll length (M): 10
Specification: ISO 11237 2SC R16S , EN 857 2SC , SAE 100R16
Tariff Code: 4009210000
Type: 2SC 2 Wire Compact

Specifications
Manufactures Specifications
Brand: Gates
Burst pressure (bar): 688
Burst pressure (psi): 10000
Construction: 2 Wire
Hose inner Ø (ins): 1
Hose outer Ø (mm): 35.1
Maximum Working Pressure (bar): 172
Maximum Working Pressure (psi): 2500
Minimum Bend Radius (mm): 115
Nominal I.D.: DN25
Pack Type: Roll
Reference: 16M2T
Roll length (M): 10
Specification: ISO 11237 2SC R16S , EN 857 2SC , SAE 100R16
Tariff Code: 4009210000
Type: 2SC 2 Wire Compact

Suitable For Information
This product is not associated with any particular make or model
