Gates Hydraulic Hose – 3/8” 2SC 2 Wire Compact (Roll) | Sparex Part Number: S.118124 0.42 kg

Brand: Gates
Burst pressure (bar): 1400
Burst pressure (psi): 20000
Construction: 2 Wire
Hose inner Ø (ins): 3/8
Hose outer Ø (mm): 17.5
Maximum Working Pressure (bar): 350
Maximum Working Pressure (psi): 5000
Minimum Bend Radius (mm): 50
Nominal I.D.: DN10
Pack Type: Roll
Reference: 6M2T
Roll length (M): 30
Specification: ISO 11237 2SC R16S , EN 857 2SC , SAE 100R16
Tariff Code: 4009210000
Type: 2SC 2 Wire Compact

Specifications
Manufactures Specifications
Brand: Gates
Burst pressure (bar): 1400
Burst pressure (psi): 20000
Construction: 2 Wire
Hose inner Ø (ins): 3/8
Hose outer Ø (mm): 17.5
Maximum Working Pressure (bar): 350
Maximum Working Pressure (psi): 5000
Minimum Bend Radius (mm): 50
Nominal I.D.: DN10
Pack Type: Roll
Reference: 6M2T
Roll length (M): 30
Specification: ISO 11237 2SC R16S , EN 857 2SC , SAE 100R16
Tariff Code: 4009210000
Type: 2SC 2 Wire Compact

Suitable For Information
This product is not associated with any particular make or model
